H05V-K/MTW/TEW
NFPA 79`a göre sanayi tesisleri için PVC izolasyonlu döşeme kablosu, HAR/ VDE/ UL/ CSA sertifikalı
Marking for H05V-K/MTW/TEW 31660180: SAB BRÖCKSKES · D-VIERSEN · < VDE > < HAR > H05V-K 1,0 mm² 18 AWG (UL) Type MTW 600V AWM Style 1015/10519 105°C 600V VW1 CSA Type TEW 105°C 600V FT1 CE
Kullaniş
H05V-K/MTW/TEW is a PVC insulated wiring cable that has a NFPA 79 certification. It is recommendes for use in construction of control cabinets, appliances and devices for communication technologies, household appliances, generator, transformer and machine construction.
Özel özellikler
- 300/500 V
- flexible conductor
- harmonised acc. to European standards
- MTW (Machine Tool Wire)
- TEW (Thermoplastic Equipment Wire)
- NFPA 79 for industrial machinery
Yapı
| Conductor | tinned copper strands acc. to IEC 60228, EN 60228, VDE 0295, class 5 |
|---|---|
| Insulation | PVC, TI1 acc. to DIN VDE 0281 part 1 + HD 21.1 |
| Sheath colour | black (RAL 9005) |
tinned copper strands acc. to IEC 60228, EN 60228, VDE 0295, class 5
PVC, TI1 acc. to DIN VDE 0281 part 1 + HD 21.1
black (RAL 9005)
Teknik veriler
| Nominal voltage | DIN VDE: Uo/U 300/500 V UL/CSA: 600 V |
|---|---|
| Testing voltage | 2000 V acc. to EN 50395 |
| Min. bending radius | 4 x d |
| Temperature range | DIN VDE fixed laying: -40/+70°C DIN VDE flexible application: +5/+70°C
UL-AWM/CSA fixed laying: up to +105°C UL-AWM/CSA flexible application: up to +105°C
(UL) MTW fixed laying: up to +90°C (UL) MTW flexible application: up to +90°C |
| Fire performance | flame retardant and self-extinguishing acc. to IEC 60332-1-2 and EN 60332-1-2, UL VW-1, CSA FT1 |
| Absence of harmful substances | acc. to RoHS directive of the European Union |
DIN VDE: Uo/U 300/500 V
UL/CSA: 600 V
2000 V acc. to EN 50395
4 x d
DIN VDE fixed laying: -40/+70°C
DIN VDE flexible application: +5/+70°C
UL-AWM/CSA fixed laying: up to +105°C
UL-AWM/CSA flexible application: up to +105°C
(UL) MTW fixed laying: up to +90°C
(UL) MTW flexible application: up to +90°C
flame retardant and self-extinguishing acc. to IEC 60332-1-2 and EN 60332-1-2, UL VW-1, CSA FT1
acc. to RoHS directive of the European Union
